Kamera Sensorius 1/1.8" Progressive Scan CMOS Maks. rezoliucija 3840 × 2160 Min. apšvietimas Color: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light Užrakto greitis 1/3 s to 1/100,000 s Day & Night IR cut filter Kampo keitimas Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360° Lęšis Lęšio tipas Fixed focal lens, 2.8 and 4 mm optional Focal Length & FOV 2.8 mm, horizontal FOV 105.1°, vertical FOV 54.8°, diagonal FOV 128.2°
4 mm, horizontal FOV 90.0°, vertical FOV 45.8°, diagonal FOV 109.4°
Lęšio montavimas M16 Rainelės tipas Fixed Diafragama F1.0 Ryškumo gylis 2.8 mm: 3.3 m to ∞
4 mm: 3.8 m to ∞
DORI DORI 2.8 mm: D: 89 m, O: 35 m, R: 17 m, I: 8 m
4 mm: D: 109 m, O: 43 m, R: 21 m, I: 10 m
Apšvietimas Papildomo apšviešimo tipas IR,White Light Papildomo apšvietimo diapazonas Up to 40 m Išmanus papildomas apšvietimas Yes IR bangos ilgis 850 nm Vaizdas Pagrindinis srautas 50 Hz:
25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
24 fps (3840 × 2160)
30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Antrinis srautas 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Trečias srautas 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings.
Vaizdo suspaudimas Main stream: H.265/H.264/H.264+/H.265+,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264,
*Third stream is supported under certain settings.
Vaizdo bitų greitis 32 Kbps to 16 Mbps H.264 tipas Baseline Profile,Main Profile,High Profile H.265 tipas Main Profile Bitų greičio kontrolė CBR,VBR Scalable Video Coding (SVC) H.264 and H.265 encoding Region of Interest (ROI) 1 fixed region for main stream and sub-stream Garsas Garso suspaudimas -U: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC Garso bitų greitis -U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 Kbps to 64 Kbps (AAC-LC)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3) Garso atrankos dažnis -U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Pašalinių garsų šalinimas -U: Yes Internetas Protokolai TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP Tiesioginis vaizdo žiūrėjimas Up to 6 channels API Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP User/Host Up to 32 users
3 user levels: administrator, operator, and user
Saugumas Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address) Vidinė atmintis NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR) Klientas iVMS-4200,Hik-Connect,Hik-Central Naršyklė Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Nuotrauka Nuotraukos parametrų keitiklis Yes Nuotraukos nustatymai Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser Diena/Naktis režimas Day,Night,Auto,Schedule Nuotraukų pagražinimas BLC,HLC,3D DNR SNR ≥ 52 dB Wide Dynamic Range (WDR) 130 dB Privatumo kaukė 4 programmable polygon privacy masks Sąsaja Interneto sąsaja 1 RJ45 10 M/100 M self-adaptive Ethernet port Vidinė atmintis
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Įmontuotas mikrofonas -U: Yes Perkrovimo mygtukas Yes Funkcijos Pagrindinės funckcijos Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception Sąsaja Upload to FTP/NAS/memory card,notify surveillance center,trigger recording,trigger capture,send email Išmaniosios funkcijos Scene change detection Išmaniosios funkcijos Veido atpažinimas Yes Perimeter Protection Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
Pagrindinis Sistemos parametrai 12 VDC ± 25%, 0.58 A, max. 7 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 8.5 W
Medžiaga Front cover: Metal, body: Metal, bracket: Metal Dydis Ø74.4 mm × 179.2 mm (Ø2.9" × 7.1") Pakuotės dydis 234 mm × 120 mm × 117 mm (9.2" × 4.7" × 4.6") Svoris Approx. 525 g (1.2 lb.) Svoris su įpakavimu Approx. 750 g (1.7 lb.) Sandėliavimo sąlygos -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Darbo sąlygos -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Pagrindinės funkcijos Heartbeat,mirror,password reset via email,pixel counter,anti-banding Kalba 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian Patvirtinimai EMC
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015,
RCM: AS/NZS CISPR 32: 2015
Saugumas UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
Aplinkosauga CE-RoHS: 2011/65/EU Apsauga IP67: IEC 60529-2013
Kodas
KIP2CD2087G2HLIUEFF4
