Kamera Sensorius 1/3" Progressive Scan CMOS Maks. rezoliucija 2560 × 1440 Min. apšvietimas Color: 0.001 Lux @ (F1.0, AGC ON),0 Lux with light Užrakto greitis 1/3 s to 1/100,000 s Day & Night 24/7 color imaging Kampo keitimas Pan: 0° to 360°,tilt: 0° to 180°,rotate: 0° to 360° Lęšis Lęšio tipas Fixed focal lens, 4 and 6 mm optional Focal Length & FOV 4 mm, horizontal FOV: 75°, vertical FOV: 40°, diagonal FOV: 89°
6 mm, horizontal FOV: 49°, vertical FOV: 27°, diagonal FOV: 57°
Lęšio montavimas M12 Rainelės tipas Fixed Diafragama F1.0 Ryškumo gylis 4 mm: 2.7 m to ∞
6 mm: 6 m to ∞
DORI DORI 4 mm, D: 82 m, O: 32 m, R: 16 m, I: 8 m
6 mm, D: 120 m, O: 47 m, R: 24 m, I: 12 m
Apšvietimas Papildomo apšviešimo tipas White Light Papildomo apšvietimo diapazonas Up to 50 m Išmanus papildomas apšvietimas Yes Vaizdas Pagrindinis srautas 50 Hz:
20 fps (2560 × 1440)
25 fps (1920 × 1080, 1280 × 720)
60 Hz:
20 fps (2560 × 1440)
24 fps (1920 × 1080, 1280 × 720)
Antrinis srautas 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)
Vaizdo suspaudimas Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG
Vaizdo bitų greitis 32 Kbps to 8 Mbps H.264 tipas Baseline Profile,Main Profile,High Profile H.265 tipas Main Profile Bitų greičio kontrolė CBR,VBR Region of Interest (ROI) 1 fixed region(s) for main stream Garsas Garso tipas -U: Mono sound Pašalinių garsų šalinimas -U: Yes Garso atrankos dažnis -U: 8 kHz/16 kHz Garso suspaudimas -U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC Garso bitų greitis -U: 64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) Internetas Protokolai TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP Tiesioginis vaizdo žiūrėjimas Up to 6 channels API Open Network Video Interface (Profile S, Profile T, Profile G (only -U model supports)),ISAPI,SDK User/Host Up to 32 users
3 user levels: administrator, operator, and user
Saugumas Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) Klientas iVMS-4200,Hik-Connect Naršyklė Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Firefox 52.0+
Nuotrauka Wide Dynamic Range (WDR) 120 dB SNR ≥ 52 dB Diena/Naktis režimas Day,Night,Auto,Schedule Nuotraukų pagražinimas BLC,HLC,3D DNR Nuotraukos nustatymai Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser Privatumo kaukė 4 programmable polygon privacy masks Sąsaja Interneto sąsaja 1 RJ45 10 M/100 M self-adaptive Ethernet port Vidinė atmintis Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB Įmontuotas mikrofonas -U: Yes Perkrovimo mygtukas -F: Yes Funkcijos Pagrindinės funckcijos Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception Sąsaja Upload to FTP/memory card (-F), notify surveillance center, send email, trigger recording (-F), trigger capture Pagrindinis Sistemos parametrai 12 VDC ± 25%, 0.4 A, max. 5 W,Ø5.5 mm coaxial power plug,
PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
Medžiaga Front cover: metal, body: plastic, bracket: metal Dydis 83.7 mm × 80.7 mm × 205.6 mm (3.3" × 3.2" × 8.1") Pakuotės dydis 260 mm × 125 mm × 125 mm (10.2" × 4.9" × 4.9")
-L: Approx. 560 g (1.2 lb.); -LUF: Approx. 580 g (1.3 lb.)
Svoris su įpakavimu
-L: Approx. 615 g (1.4 lb.); -LUF: Approx. 635 g (1.4 lb.)
Sandėliavimo sąlygos -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Darbo sąlygos -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Kalba English, Ukrainian Pagrindinės funkcijos Heartbeat,anti-banding,mirror,password protection,password reset via email Patvirtinimai EMC FCC: 47 CFR Part 15, Subpart B,
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
RCM: AS/NZS CISPR 32: 2015,
KC: KN32: 2015, KN35: 2015
Saugumas UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
Aplinkosauga CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
Apsauga IP67: IEC 60529-2013
Kodas
KIPDS2CD1T47G2LUFF4
