Kamera Sensorius 1/2.7" Progressive Scan CMOS Min. apšvietimas Color: 0.003 Lux @ (F1.4, AGC ON) Užsisklendimo greitis 1/3 s to 1/100,000 s Lėtas užsisklendimas Yes P/N P/N Platus dinaminis diapozonas 120 dB Diena & Naktis ICR Cut Kampo pasirinkimas Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° Lęšiai Lęšių diapozonas & FOV 2.8 mm, horizontal FOV: 103°, vertical FOV: 55°, diagonal FOV: 123°
4 mm, horizontal FOV: 83°, vertical FOV: 45°, diagonal FOV: 98°
6 mm, horizontal FOV: 53°, vertical FOV: 29°, diagonal FOV: 62°
Diafragma F1.4 Lęšio montavimas M12 Apšvietimas IR diapozonas Up to 60 m IR bangų ilgis 850 nm Išmani pagalbinė šviesa Yes Vaizdo signalizacija Yes Video Maks. raiška 2592 × 1944 Pagrindinis srautas 50Hz: 20fps (2592 × 1944)
25fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2592 × 1944)
30fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720)
Pagalbinis srautas 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Tretinis srautas 50Hz: 25fps (1280 × 720, 640 × 480, 640 × 360, 360 × 240)
60Hz: 30fps (1280 × 720, 640 × 480, 640 × 360, 360 × 240)
Vaizdo suspaudimas Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
Vaizdo bitų greitis 32 Kbps to 8 Mbps H.264 tipas Baseline Profile/Main Profile/High Profile H.265 tipas Main Profile H.264+ Main Stream supports H.265+ Main Stream supports Bitų dažnio kontrolė CBR/VBR SVC Yes ROI 1 fixed region for each stream Garsas Aplinkos triukšmo filtravimas Yes Garso pavyzdžių ėmimo dažnis 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Garso suspaudimas G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3 Garso bitų greitis 64Kbps(G.711ulaw/G.711alaw)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8-320Kbps(MP3) Tinklas Tiesioginis vaizdo žiurėjimas Up to 6 channels API ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK Protokolai TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, SNMP Sklandus srautas Yes User/Host Up to 32 users. 3 user levels: administrator, operator and user Apsauga Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.2, WSSE and digest authentication for ONVIF Tinklo saugykla microSD/SDHC/SDXC card (256 GB) local storage, and NAS(NFS, SMB/CIFS), auto network replenishment (ANR)
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Klientas iVMS-4200, Hik-Connect, Hik-Central Interneto naršyklės Plug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Vaizdas Dienos/Nakties jungiklis Day, Night, Auto, Schedule Vaizdo gerinimas BLC, HLC, 3D DNR Vaizdo parametrų jungiklis Yes Vaizdo parametrai Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser Sąsaja Signalizacija 1 input, 1 output (max. 24 VDC, 1 A or max. 24 VAC, 1 A) Garsas 1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance:4.7 KΩ, interface type: non-equilibrium;
1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium;
1 built-in speaker, 1 built-in microphone
Vidinė Atmintis Built-in micro SD/SDHC/SDXC slot, up to 256 GB Aparatinės įrangos atkūrimas Yes Etherneto jungtis 1 RJ45 10M/100M self-adaptive Ethernet port Gilaus mokymosi funkcija Veido atpažinimas Yes Perimetro apsauga Line crossing detection, intrusion detection, region entrance detection, region exiting detection Išmanus (Tradicinis algoritmas) Paprasti įvykiai Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), scene change detection Pagrindins Sujungimo metodas Upload to NAS/memory card, notify surveillance center, trigger record, trigger capture, strobe light, audible warning
*Note: External device is required.
Meniu kalbos 33 languages:
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
Pagrindinės funkcijos Anti-flicker, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter Programinės įrangos atkūrimas Yes Laikymo sąlygos -30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing) Paleidimo ir veikimo sąlygos -30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing) Energijos šaltinis 12 VDC ± 25%; PoE: 802.3af, Class3 Energijos suvartojimas ir galia 12 VDC, 0.88 A, max. 10.5 W; PoE: (802.3af, 36 V to 57 V), 0.34 A to 0.21 A, max. 12.5 W Energijos jungtis Ø5.5 mm coaxial power plug Kameros matmenys Ø105 × 287.6 mm (Ø4.1" × 11.3") Pakuotės matmenys 386 × 156 × 155 mm (15.2" × 7.5" × 7.1") Kameros svoris Approx. 1120 g (2.5 lb.) Svoris su pakuote Approx. 1634 g (3.6 lb.) Certifikatai EMC FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) Saugumo UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 ); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 ); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) Aplinkosaugos CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) Apsaugos nuo skysčių ir dulkių Ingression protection: IP67 (IEC 60529-2013)
Kodas
KIP2CD2T46G2ISUSLFB
