Pagrindinis Sensorius 1/2.9" CMOS Maks. rezoliucija 2688 (H) × 1520 (V) ROM 128 MB RAM 128 MB Skenavimo sistema Progressive Elektroninis užrakto greitis Auto/Manual 1/3 s–1/100,000 s Min. apšvietimas 0.006 lux@F1.6 (Color, 30 IRE), 0.0006 lux@F1.6 (B/W, 30 IRE), 0 lux (Illuminator on) S/N santykis >56 dB Apšvietimo atstumas up to 30 m (98.43 ft) (IR), up to 30 m (98.43 ft) (Warm light) Apšvietimo valdymas Auto; Manual Apšvietimo skaičius 1 (IR LED), 1 (Warm light) Pan/Tilt/Rotation Range Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360° Lęšio tipas Fixed-focal Lęšio montavimas M12 FOV 2.8 mm, 3.6 mm Maks. diafragma F1.6 FOV 2.8 mm: H: 95°, V: 52°, D: 114°; 3.6 mm: H: 78°, V: 41°, D: 94° Diafragmos valdymas Fixed Artimiausias fokusavimas 2.8 mm: 0.9 m (2.95 ft), 3.6 mm: 1.6 m (5.25 ft) DORI atstumas 2.8 mm: Detect 63.6 m (208.66 ft), Observe 25.4 m (83.33 ft), Recognize 12.7 m (41.67 ft), Identify 6.4 m (20.99 ft); 3.6 mm: Detect 85.4 m (280.18 ft), Observe 34.2 m (112.20 ft), Recognize 17.1 m (56.10 ft), Identify 8.5 m (27.89 ft) IVS (Perimeter Protection) Intrusion, tripwire (supports classification and accurate detection of vehicle and human) Išmanioji paieška Works with Smart NVR for refined intelligent search, event extraction, and merging to event videos Vaizdo suspaudimas H.264H, H.265, H.264, H.264B, MJPEG (Only supported by the sub stream) Išmanusis kodekas Smart H.265+, Smart H.264+ Vaizdo kadrų dažnis Main stream: 2688 × 1520@(1–20 fps)/2566 × 1440@(1–25/30 fps), Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) (*Max frame rates per stream; multiple streams subject to total encoding capacity) Srauto pajėgumas 2 streams Rezoliucija 4M (2688 × 1520), 3.6M (2560 × 1440), 3M (2304 × 1296), 1080p (1920 × 1080), 1.3M (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240) Bitų greičio kontrolė CBR/VBR Vaizdo bitų greitis H.264: 32 kbps–6144 kbps, H.265: 12 kbps–6144 kbps Dienos/nakties režimas Auto (ICR)/Color/B/W BLC Yes HLC Yes WDR 120 dB Baltos spalvos balansas Auto, natural, street lamp, outdoor, manual, regional custom Stiprinimo valdymas Auto, Manual Triukšmo mažinimas 3D NR Judesių aptikimas OFF/ON (4 areas, rectangular) Intereso sritis Yes (4 areas) Išmanusis apšvietimas Yes Vaizdo rotacija 0°/90°/180°/270° (Supports 90°/270° with 2688 ×1560 resolution and lower) Veidrodis Yes Privatumo maskavimas 4 areas Integruotas mikrofonas Yes Garso suspaudimas G.711a, G.711Mu, PCM, G.726 Alarm Events No SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, motion detection, video tampering, tripwire, intrusion, SMD, voltage detection, security exception Tinklo prievadas RJ-45 (10/100 Base-T) SDK ir API Yes Protokolai IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP, P2P Suderinamumas ONVIF (Profile S/Profile G/Profile T), CGI Naudotojas/prievadas 6 (Total bandwidth: 36 M) Saugykla FTP, SFTP, Micro SD card (max. 256 GB) Naršyklė IE, Chrome, Firefox Valdymo programinė įranga DSS, DMSS Mobilioji programa iOS, Android Kibernetinis saugumas Configuration encryption, Trusted execution, Digest, Security logs, WSSE, Account lockout, syslog, Video encryption, 802.1x, IP/MAC filtering, HTTPS, Trusted upgrade, Trusted boot, X.509 certification support Sertifikatai CE-LVD: EN62368-1, CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU, FCC: 47 CFR FCC Part 15, Subpart B, UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 Maitinimas 12 VDC/PoE (802.3af) Energijos sunaudojimas Basic: 2.1 W (12 VDC), 2.5 W (PoE); Max. (H.265 + intelligence + WDR + warm light): 4.4 W (12 VDC), 5.2 W (PoE) Darbo sąlygos (temperatūra) –40 °C to +60 °C (–40 °F to +140 °F) Darbo sąlygos (drėgmė) ≤95% Sandėliavimo sąlygos temperatūra –40 °C to +60 °C (–40 °F to +140 °F) Apsauga IP67 Korpuso medžiagas Metal Produkto dydis 166.2 mm × 70 mm × 70 mm (6.54" × 2.76" × 2.76") (L × W × H) Svoris be įpakavimo 0.48 kg (1.06 lb) Svoris su įpakavimo 0.59 kg (1.30 lb)
Kodas
DAHIPCH2449SSIL0280B
