- General
- Dimensions72 × 72 × 152 mm (2.83 ×2.83 × 5.98 inch)
- Packaging Dimensions227 × 100 × 92 mm (8.94 ×3.94 × 3.62 inch)
- Net WeightProduct: 256 g (9.03 oz),With package: 500 g (17.64 oz)
- IP GradeIP67
- Operation Conditions-4 °F to 122 °F (-20 °C to50 °C )Humidity 95% or less (non-condensing)
- Camera
- Image Sensor1/2.7” Progressive ScanCMOS
- Minimum Illumination0.01 Lux @ (F2.0, AGC ON),0 Lux with IR
- IR Night Vision DistanceUp to 98 ft / 30 m
- Shutter SpeedSelf-adaptive shutter
- Lens2.8 mm @ F2.0, view angle:106° (Horizontal), 122°(Diagonal)
- Lens MountM12
- DNR3D DNR
- WDRDigital WDR
- Video & Audio
- Max. Resolution2MP, 1920 × 1080
- Video CompressionH.265 / H.264
- Video Bit RateFull HD; HD; Standard.Adaptive bit rate
- Frame RateMax: 30fps; Self-Adaptiveduring network transmission
- Max. Bitrate2 Mbps
- Network
- Wi-Fi PairingAP pairing
- ProtocolEZVIZ cloud proprietaryprotocol
- Interface ProtocolEZVIZ cloud proprietaryprotocol
- Wi-Fi StandardIEEE802.11b, 802.11g,802.11n
- Channel BandwidthSupports 20MHz
- Wired NetworkRJ45 × 1(10M / 100MAdaptive Ethernet Port)
- Transmission Rate11b: 11Mbps,11g:54Mbps,11n: 144Mbps
- Frequency Range2.4GHz ~ 2.4835 GHz
- Functions
- DetectionMotion Detection
- General FunctionAnti-Flicker, Dual-Stream,Heart Beat, Mirror Image,Password Protection, Watermark
- Security64 / 128-bit WEP, WPA /WPA2, WPA-PSK / WPA2-PSK
- Storage
- Local StorageSupports microSD card (Upto 256 GB)
- Cloud StorageSupports EZVIZ CloudPlaystorage (Subscription required)
- Power
- Power SupplyDC 12V / 1A
- Power ConsumptionMax. 6W
- In the boxIn the box- C3TN Color Camera
- Drill Template- Screw Kit- Waterproof Kit- Power Adapter- RegulatoryInformation- Quick Start Guide
- Certifications
- CertificationsCE / WEEE / REACH / RoHS /UL / FCC / UKCA
CSH3C1080P28MMCOLOR
